IBM DDRS-39130 (9.1GB)

3 1/2" 7200 RPM Single Ended Ultra-1 SCSI

A14 / A16 / A20 / A23 / A25 / A26
Netra t 1120 / Netra t 1125 / Netra ft 1800 / Netra t1 / E3000
StorEdge A1000 / StorEdge D1000 / StorEdge A7000
StorEdge MultiPack / StorEdge UniPack

Options 5163 / 5229 / 5230 / 6288 / 6956

370-3404 540-3704 540-3720 540-4004
1" Height
Draco 9
Ultrastar 9ES		 Spud Bkt FRU
w 1" Bkt 540-3024		 12-Slot A1000/D1000 FRU
w 1" Bkt 540-3024
w Plate 340-4288 or 340-6640
or Plate 340-5928 or 340-7269		 Netra ft 1800 FRU

Notes

  1. The LVD capability of this drive is not qualified by Sun.
  2. The 40/80Mbyte/sec capability of this drive is not qualified by Sun.
  3. The 9.1GB Drive is not compatible with A7000 Option 9652, Chassis 540-3666.
  4. The 9.1GB Drive requires A7000 Option 9656, Chassis 540-3841.

Reference

9 Gbyte Disk Drive Specification, 805-3935.
