MG2

1-Bit Analog Frame Buffer

Sun-4/15/30/40/50/60/65/75
SS4 / SS5 / SS10 / SS20 / SS600

501-1455	501-8062
	w 4/E Backpanel

UNIX ID: /dev/bwtwo0

Power:

0.4 Amps @ +5Vdc

2.0 Watts

Notes

1. The final software release is Solaris 2.6.
2. The MG2 Frame Buffer produces a 1-bit Analog output.

UNIX ID: /dev/bwtwo0

Power:

0.3 Amps @ +5Vdc

1.6 Watts

Notes

1. The final software release in Solaris 2.6.
2. The MG2 Frame Buffer produces a 1-bit Analog output.
