32MB NVRAM Board

Notes

1. The minimum operating system is Solaris 2.5.1.
2. Device drivers for the NVRAM Board are in Netra NFS 1.2.
3. The 375-0012-02 fixes BugID 4085112.
4. Use the nvadm -v command to display the board status bits.


   Battery	0x00	Normal operation
   Battery	0x01	Battery 1 has open fuse or is not enabled
   Battery	0x02	Battery 1 has low voltage
   Battery	0x04	Battery 2 has open fuse or is not enabled
   Battery	0x08	Battery 2 has low voltage
   Battery	0x10	Battery 3 has open fuse or is not enabled
   Battery	0x20	Battery 3 has low voltage
   Dirty Bit	0x00	No valid data is present (Cache Data LED if Off)
   Dirty Bit	0x01	Valid data is present and the cache is dirty (Cache Data LED is On)

Reference

Installation and Users Guide, 805-1378.
