| CODE |
PART # |
DESCRIPTION |
1
1 |
540-1778
540-2431 |
Cover Assembly
Modified Cover Assembly for 557-KDK Option |
2
3
4
NS
NS |
540-1978
150-2049
540-2185
150-1174
340-2839 |
Fan/SCSI Connector/Address Select Assembly/FRU
 Address Select Switch
Fan Assembly
2A Subminiature Fuse
Fan EMI Gasket |
5
6 |
540-1773
330-1214 |
Base Assembly
Rubber Foot |
| 7 |
300-1105 |
44 Watt Power Supply |
8
9
10
11
NS
NS |
540-2449
370-1573
340-1967
530-1825
240-1530
250-1194 |
CD-ROM Assembly for 557-KDK Option
Sony CDU-561 CD-ROM
Drive Bracket
Address Switch Cable, 0.10" Pin Spacing, 8.5"
M3 0.5 × 6mm Screw
Adhesive Backed RFI Strip, 140 mm |
8
9
10
11
NS |
540-2478
370-1584
340-1967
530-1825
240-1141 |
CD-ROM Assembly
Sony CDU-561 CD-ROM
Drive Bracket
Address Switch Cable, 0.10" Pin Spacing, 8.5"
#6-32 × 1/4" Screw |
| NS |
150-1785 |
External Active Terminator, HD50 |
| NS |
530-1793 |
External SCSI Cable, HD50 to HD50, 80 cm |
| NS |
530-1836 |
External SCSI Cable, HD50 to HD50, 2.0M |
| NS |
530-1852 |
External SCSI Cable, HD50 to HD50, 4.0M |
| NS |
800-4895 |
SunCD Plus Desktop Pack Installation Manual |
