Power

1.04 Amps @ +5Vdc

5.2 Watts

Notes

1. The minimum operating system is Solaris 1.1 (SunOS 4.1.3).
2. Set the SS10 clock speed to 66MHz.
3. Only one SM30 is supported.
4. The 270-1733-08, -09, and -10 FABs require a crystal change.

Reference

SuperSPARC Module Installation Guide, 801-2035.

Power

2.62 Amps @ +5Vdc

13.10 Watts

Notes

1. The minimum operating system is Solaris 1.1 (SunOS 4.1.3).
2. Set the SS10 clock speed to 72MHz.
3. The 270-1733-08, -09, and -10 FABs require a crystal change.
4. Only one SM30 is supported.
5. This module is not supported in the SS10 Model 20.

Reference

SuperSPARC Module Installation Guide, 801-2035.
