CG8 24-bit Color Frame Buffer
Sun-4/110/150
| 501-1371 |
501-1518 |
501-1577 |
| BNC |
DB13W3 |
w 3/80 Rear Panel
DB13W3 |
UNIX ID: /dev/cgeight0
Power
| 501-1371 and 501-1518 |
501-1577 |
5.5 Amps @ +5Vdc
27.5 Watts |
4.8 Amps @ +5Vdc
24.0 Watts |
Notes
- There are no jumpers or switches on this board.
- Set CPU EEPROM location 0x1F to 0x20.
- Requires SunOS 4.0 CG8 or 4.0.3 or greater.
- SunOS 4.0 CG8 is not upgradeable to 4.0.1.
- CG8 must be 501-1374-04 or greater for use with Sun 3400 and Sun 4300 CPU boards.
- The CG8 is not supported under OpenWindows Versions 2 or 3.
Last updated: December 2, 1996
|
|
|
