Seagate ST318203FC (18.2GB)

3 1/2" 10000 RPM FC-AL

A28 / A29 / E3500 / StorEdge A5200 / StorEdge T3

Options 6716 / 6720 / 6728

390-0011 390-0022
1" Height
Cheetah 18LP
Assy 540-4191
Assy 540-4673		 1" Height
Cheetah 18LP
Assy 540-4440
540-4191 540-4440 540-4673
Spud Bracket FRU
w 1" Bkt 540-3024
w Plate 340-5928
or Plate 340-6640
or Plate 340-7269		 T3 FRU
w Bkt 540-4303		 Spud Bracket FRU
w 1" Bkt 540-3024
w Plate 340-6640
or Plate 340-7269

Notes

  1. Drives 390-0011 and 390-0022 are the same Seagate model number.
  2. Drives 390-0011 and 390-0022 are not interchangeable because they have different firmware and different mode sense data.
  3. Plate 340-5928 is not compatible with the Sun Blade 1000 (A28) or 2000 (A29).

Reference

18 Gbyte 10000 rpm Disk Drive Specifications, 806-1493.
