Seagate ST318304FC (18.2GB)
3 1/2" 10000 RPM FC-AL
A28 / A29 / E3500 / StorEdge A5200 / StorEdge T3
Options 6716 / 6720 / 6728
| 390-0034 |
390-0053 |
1" Height
Cheetah 36LP
Assy 540-4191
Assy 540-4673 |
1" Height
Cheetah 36LP
Assy 540-4440 |
| 540-4191 |
540-4440 |
540-4673 |
Spud Bracket FRU
w 1" Bkt 540-3024
w Plate 340-5928
or Plate 340-6640
or Plate 340-7269 |
T3 FRU
w Bkt 540-4303 |
Spud Bracket FRU
w 1" Bkt 540-3024
w Plate 340-6640
or Plate 340-7269 |
Notes
- Drives 390-0034 and 390-0053 are the same Seagate model number.
- Drives 390-0034 and 390-0053 are not interchangeable because they have
different firmware and different mode sense data.
- Plate 340-5928 is not compatible with the Sun Blade 1000 (A28) or 2000 (A29).
- Solaris 2.5.1 Patch
 105310-05,
2.6 Patch
105375-10,
or <2.7 11/99 Patch
107469-08
is required for non-boot disk drives.
- Solaris 2.5.1 and 2.6 boot drives require the workaround described in
FIN I0645-1.
No workaround is available for Solaris <2.7 11/99.
Reference
-
18 GByte 10000 rpm Disk Drive Specifications, 806-1493.
|
